Detail Description:
Ingersoll Rand Infinity Air Winch Series
Model : FA5i-24M1KG
Capacity @ top layer : 5000 kg
Top layer line speed : 16 m/min (54 fpm)
Drum length : 24 inch
Motor rate : 18,8 kW / 25,2 HP
Air Consumption : 20 m 3 /min (700 scfm)
Reccommended Pipe inlet size : 1-1/4"
Reccommended Hose size: 1-1/2"
Weight : 849 Kg
Reccommended wire rope: 3/4 " (19 mm), with maximum storage 347 m
Brake : No Manual Drum, Auto Disc
Control : Std. Throttle lever
Protection : Drum Guard
Exclude wire rope (purchase separately)
Complete with :
- Certificate Of Origin
- Certificate Of Conformance
- Certificate of Manufacturer
- Warranty Certificate
- Manual Book
